Specs & Information
- FRAME
- Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29” Wheels, 125mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
- FRONT SUSPENSION
- Fox 36 Performance Elite Float, 140mm Travel, GRIP 2 Damper, 110x15mm Kabolt Axle, 44mm Offset
- REAR SUSPENSION
- Fox Factory Series Coil, Coil Spring, Climb Switch, Rebound & Compression Adjustment, Custom Tune, 210x50mm, M8x30mm Top, M8x25mm Bottom, Spring rates: S = 350lb, M = 400lb, L = 450lb, XL = 500 lb
- RIMS
- Marin Aluminum Double Wall, 29mm Inner, Welded Joint, Disc Specific, Tubeless Compatible
- HUB, REAR
- Forged Alloy, 148x12mm,Disc, 32H, MS Freehub Body
- HUB, FRONT
- Forged Alloy, 148x12mm,Disc, 32H, MS Freehub Body
- SPOKE, NIPPLES
- 14g Black Stainless Steel
- TIRES
- Maxxis Assegai 29x2.5”, 3C MaxxGrip, EXO+, Tubeless Compatible
- DERAILLEUR, REAR
- Shimano XT, 12-Speed, SGS
- SHIFT LEVER
- Shimano SLX, 12-Speed, SL-7100R
- CRANKSET
- FSA Gradient, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, MegaExo Spindle, Boost Spacing
- BOTTOM BRACKET
- MEGAEVO BB, 73mm BSA Threaded
- CHAIN
- KMC X-12 Silver and Black
- CASSETTE
- Shimano Deore M6100, 12-Speed, 10-51T
- BRAKE, FRONT
- Shimano XT, 4-Piston Hydraulic Disc, 203mm Rotor
- BRAKE, REAR
- Shimano XT, 4-Piston Hydraulic Disc, 180mm Rotor
- BRAKE LEVERS
- Shimano XT Hydraulic, I-Spec EV
- HANDLEBAR
- Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
- STEM
- Marin CNC, 35mm Length, 35mm Bar Bore
- GRIPS
- Marin Grizzly Lock On
- HEADSET
- FSA No 42/47, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
- SEATPOST
- X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
- SADDLE
- Marin Trail Speed Concept Pro
- EXTRAS
- Bolt-On Thru-Axle
|
|
|
|
|
|
|
